Case 610 (1958–1960)

Traduction française indisponible ; contenu anglais affiché.

Années de production: 1958–1960 • Usine d’assemblage: Racine, Wisconsin, USA

Puissance moteur
62 HP
PDF : 38.58 ch
Cylindrée
3.4 L
Moteur 4 cylindres
Entraînement et châssis
Tracks (Crawler)
Power shift (4-speed)
Poids en ordre de marche
4,313 kg
9,510 lbs

Sources et preuves par champ

Cette fiche importée ne contient pas encore de preuves au niveau des champs.

Case 610 (1958–1960)
VLM Verified Authentic
Case 610 (1958–1960)

Ask TractorDex AI Copilot About 610

Instant technical consultation powered by heavy machinery knowledge

Engineering & Capability Benchmark

Specific output, tractive ratio, and segment percentile

Utility & Farmyard Workhorse
Global Tractor Fleet Power SpectrumTop 76% of all indexed machinery
Compact (20 HP)Utility (100 HP)Row-Crop (250 HP)Titans (600+ HP)
Specific Output
18.2 HP/L
Aspiration: Unknown
Traction Ratio
69.6 kg/HP
Heavy ballast for draft pull
PTO Efficiency
62%
38.58 PTO HP rated
Hydraulic Flow
Standard
Auxiliary implement ports

Caractéristiques du moteur et de la puissance

Modèle du moteur
Continental F-209
Carburant
Diesel
Puissance nominale
62 hp
Rated PTO Power
38.58 hp (Case specification)
Drawbar Power @ Rated Engine Speed
42.4 hp (Nebraska OECD Test 2218)
Cylindres
4
Cylindrée
3.4 L (208 ci)
Alésage / course
3.6875x4.875 inches 94 x 124 mm
Régime nominal
2250 RPM
Capacité d’huile moteur
N/A
Capacité de liquide de refroidissement
N/A

Maintenance picks for the 610

Filters, oil and common wear parts for this model.

Caractéristiques de transmission et de châssis

Type de transmission
Power shift (4-speed)
Rapports (avant / arrière)
4 avant
Système d’entraînement
Tracks (Crawler)
Empattement
62.625 in
Pneu avant
N/A
Pneu arrière
N/A
Débit hydraulique
N/A
Attelage arrière
N/A
ASABE EP496 Engineering Matcher

Implement Draft & Ballast Matcher

Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Case 610.

Overloaded / Wheel Slip Alert(114%)
CAD DRAFT SCHEMATIC • Wide-Span Field Cultivator
SOIL: Medium Tilled LoamDEPTH: 4"SPEED: 7 MPH114% LOAD
SOIL SURFACE (0.0")SUB-SURFACE PLOW PAN (~14")62 HP◄ 3,129 LBS DRAFT4" DEPTH
DRAWBAR DEMAND: 58.4 HPWIDTH / SIZE: 18 ft Width
ASABE D497.7 Tillage Specific Resistance Formula
Implement Size (ft Width)18 ft Width
18 ft WidthDefault: 4270 ft Width
Tillage / Seeding Depth4 inches (10 cm)
2"Target: 4"6"
Target Operating Field Speed7.0 mph (11.3 km/h)
5 mphRated: 7 mph9 mph
Engine Power Demand vs Rated Output70.4 HP / 62 HP Rated
0%55% (Min Load)60-85% (Sweet Spot)100% (Cap)
Draft Force
3,129 lbs
Drawbar Power
58.4 HP
Target Slip
8% - 12%
Axle Ballast Balance (Twin Track Rubber Belt )Calibrated for Wide-Span Field Cultivator (100 lbs/HP standard)
Target: 6,200 lbs
Front Axle: 62%Rear Axle: 38%
1,744 kg (3,844 lbs)1,069 kg (2,356 lbs)
Ballast Adjustment vs Base:-3,310 lbs (-1,501 kg)
Hourly Diesel Burn
2.9 gal/h
11 L/hr (est. $11/h)
Hydraulic Fan Status
Standard Draw
No fan req

Engine demand (70.4 HP) exceeds rated power (62 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.

Tractor exceeds target ballast by 1501 kg. Consider removing wheel weights to reduce soil compaction.

Instant Used Market Valuation Projector

Algorithmic resale estimate for Case 610 (1958)

Full Appraisal Tool
Operating Meter Hours3,200 hrs
Mechanical & Physical Condition
Empirical model calibrated against dealer & auction lots
Estimated Fair Market Value
$2,793
Basis: 62 HP • 68 yrs old
Auction / Wholesale
$2,290 – $2,570
Dealer Retail Asking
$2,933 – $3,296
3-Year Projected Resale Curve~5% annual retention decay
Year 2027
$2,653
Year 2028
$2,521
Year 2029
$2,395

Direct Segment Rivals & Showdowns

Head-to-head match-ups calibrated by horsepower and era

Cockshutt+9 HP
570 Super
71 HP
International Harvester+9 HP
TD-14
71 HP
Minneapolis-Moline+9 HP
GB
71 HP

Looking for a used Case 610?

Browse live listings and auction results near you.

Case

USA • 137 Models

Founded in 1842 by Jerome Increase Case, the J. I. Case Threshing Machine Company emerged as a pioneering force in agricultural machinery during the 19th century. The company gained early prominence by manufacturing steam engines, including portable engines and traction engines, which were crucial for mechanizing agriculture and construction in the United States. Alongside its steam engine innovations, Case became a leading producer of threshing machines and harvesting equipment, establishing itself as a cornerstone of American agricultural mechanization. By the early 20th century, Case expanded into the tractor market, becoming one of the largest tractor manufacturers globally. The company's commitment to quality and innovation earned it a reputation for robust and reliable machinery, serving both agricultural and construction sectors. In the mid-20th century, Case shifted its primary focus to construction equipment while maintaining a strong presence in agriculture. A pivotal moment in its history occurred in the 1980s when Case was acquired by Tenneco, leading to the 1985 merger with International Harvester's agricultural equipment division. This merger resulted in the formation of Case IH, a powerhouse brand that combined the legacies of two iconic agricultural machinery manufacturers. The new entity continued to innovate, introducing advanced technologies and expanding its global footprint.

View Full Case Lineup
