Cletrac DG

Traduction française indisponible ; contenu anglais affiché.

Années de production: 1936–1949

Puissance moteur
50 HP
PDF : 45.5 ch
Cylindrée
8.7 L
Moteur 6 cylindres
Entraînement et châssis
Tracks (Crawler)
Gear (4F/2R)
Poids en ordre de marche
5,670 kg
12,500 lbs

Sources et preuves par champ

Cette fiche importée ne contient pas encore de preuves au niveau des champs.

Cletrac DG
VLM Verified Authentic
Cletrac DG

Ask TractorDex AI Copilot About DG

Instant technical consultation powered by heavy machinery knowledge

Engineering & Capability Benchmark

Specific output, tractive ratio, and segment percentile

Utility & Farmyard Workhorse
Global Tractor Fleet Power SpectrumTop 80% of all indexed machinery
Compact (20 HP)Utility (100 HP)Row-Crop (250 HP)Titans (600+ HP)
Specific Output
5.7 HP/L
Aspiration: Unknown
Traction Ratio
113.4 kg/HP
Heavy ballast for draft pull
PTO Efficiency
91%
45.5 PTO HP rated
Hydraulic Flow
Standard
Auxiliary implement ports

Caractéristiques du moteur et de la puissance

Modèle du moteur
Hercules RXC
Carburant
Gasoline
Puissance nominale
50 hp
Rated PTO Power
45.5 hp (Cletrac specification)
Drawbar Power @ Rated Engine Speed
59.39 hp (Nebraska OECD Test 2218)
Cylindres
6
Cylindrée
8.7 L (529 ci)
Alésage / course
4.625x5.25 inches 117 x 133 mm
Régime nominal
1300 RPM
Capacité d’huile moteur
N/A
Capacité de liquide de refroidissement
41 qts (~38.8 L)

Maintenance picks for the DG

Filters, oil and common wear parts for this model.

Caractéristiques de transmission et de châssis

Type de transmission
Gear (4F/2R)
Rapports (avant / arrière)
4 avant / 2 arrière
Système d’entraînement
Tracks (Crawler)
Empattement
N/A
Pneu avant
N/A
Pneu arrière
N/A
Débit hydraulique
N/A
Attelage arrière
N/A
ASABE EP496 Engineering Matcher

Implement Draft & Ballast Matcher

Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Cletrac DG.

Overloaded / Wheel Slip Alert(141%)
CAD DRAFT SCHEMATIC • Wide-Span Field Cultivator
SOIL: Medium Tilled LoamDEPTH: 4"SPEED: 7 MPH141% LOAD
SOIL SURFACE (0.0")SUB-SURFACE PLOW PAN (~14")50 HP◄ 3,129 LBS DRAFT4" DEPTH
DRAWBAR DEMAND: 58.4 HPWIDTH / SIZE: 18 ft Width
ASABE D497.7 Tillage Specific Resistance Formula
Implement Size (ft Width)18 ft Width
18 ft WidthDefault: 4270 ft Width
Tillage / Seeding Depth4 inches (10 cm)
2"Target: 4"6"
Target Operating Field Speed7.0 mph (11.3 km/h)
5 mphRated: 7 mph9 mph
Engine Power Demand vs Rated Output70.4 HP / 50 HP Rated
0%55% (Min Load)60-85% (Sweet Spot)100% (Cap)
Draft Force
3,129 lbs
Drawbar Power
58.4 HP
Target Slip
8% - 12%
Axle Ballast Balance (Twin Track Rubber Belt )Calibrated for Wide-Span Field Cultivator (100 lbs/HP standard)
Target: 5,000 lbs
Front Axle: 62%Rear Axle: 38%
1,406 kg (3,100 lbs)862 kg (1,900 lbs)
Ballast Adjustment vs Base:-7,500 lbs (-3,402 kg)
Hourly Gasoline Burn
3.3 gal/h
12.5 L/hr (est. $12/h)
Hydraulic Fan Status
Standard Draw
No fan req

Engine demand (70.4 HP) exceeds rated power (50 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.

Tractor exceeds target ballast by 3402 kg. Consider removing wheel weights to reduce soil compaction.

Plages de numéros de série archivées (Référence catalogue)

21 années de production
Année de productionN° de série initialN° de série finalUsine d’assemblage
1936#100#299Usine non précisée
1937#300#367Usine non précisée
1938#368#465Usine non précisée
1939#466#767Usine non précisée
1940#768#1,199Usine non précisée
1941#1,200#1,363Usine non précisée
1942#1,364#1,391Usine non précisée
1943#1,392#1,463Usine non précisée
1944#1,464#1,747Usine non précisée
1945#1,748#2,355Usine non précisée
1946#2,356#2,619Usine non précisée
1947#2,620#2,851Usine non précisée
1948#2,852#3,185Usine non précisée
1949#3,186#3,297Usine non précisée
1950#3,298#3,361Usine non précisée
1951#3,362#3,401Usine non précisée
1952#3,402Fin de sérieUsine non précisée
1953#3,500,000Fin de sérieUsine non précisée
1954#0#3,501Usine non précisée
1955#3,502#3,515Usine non précisée
1956#3,516Fin de sérieUsine non précisée

Instant Used Market Valuation Projector

Algorithmic resale estimate for Cletrac DG (1936)

Full Appraisal Tool
Operating Meter Hours3,200 hrs
Mechanical & Physical Condition
Empirical model calibrated against dealer & auction lots
Estimated Fair Market Value
$2,259
Basis: 50 HP • 90 yrs old
Auction / Wholesale
$1,852 – $2,078
Dealer Retail Asking
$2,372 – $2,666
3-Year Projected Resale Curve~5% annual retention decay
Year 2027
$2,146
Year 2028
$2,039
Year 2029
$1,937

Direct Segment Rivals & Showdowns

Head-to-head match-ups calibrated by horsepower and era

Allis Chalmers+6 HP
A
56 HP
Caterpillar+4 HP
Forty
54 HP
Lanz+3.9 HP
D1506
53.9 HP

Looking for a used Cletrac DG?

Browse live listings and auction results near you.

Cletrac

USA • 24 Models

The Cleveland Tractor Company, commonly known as Cletrac, was founded in 1916 by brothers Clarence and Rollin White. The company quickly established itself as a pioneering force in the agricultural machinery sector, particularly with its focus on crawler tractors designed for small and medium-sized farms. Cletrac's early innovations in crawler technology made it a household name among American farmers, as these tractors offered superior traction and versatility in various terrains, setting a new standard for agricultural mechanization. The company's commitment to quality and innovation allowed it to thrive during the early 20th century, becoming a key player in the transition from animal to mechanical power in agriculture. • Throughout its history, Cletrac underwent significant transformations. In 1944, the company was acquired by the Oliver Farm Equipment Company, a move that strategically aligned Cletrac's crawler technology with Oliver's broader agricultural machinery offerings. This acquisition marked a pivotal moment for Cletrac, as it became part of a larger conglomerate while retaining its focus on crawler tractors. The acquisition also set the stage for further consolidation in the industry. Ironically, Oliver itself was later acquired by White Motor Corporation, a company with familial ties to Cletrac's founding family, thus creating a full-circle moment in the brand's history. Despite these changes, Cletrac's legacy in crawler tractor technology continued to influence the industry for decades. • Today, Cletrac is considered a historical brand, having ceased independent operations after its acquisition by Oliver. The brand's assets and technologies were integrated into the product lines of its parent companies, contributing to the development of more advanced agricultural machinery. Cletrac's most notable models, such as the Model DG and the Model HG, are remembered for their durability and performance, leaving a lasting impact on the agricultural machinery landscape. The brand's headquarters were originally located in Cleveland, Ohio, reflecting its strong regional roots and connection to the industrial heartland of America.
