Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About 9455
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Detroit Diesel 40
- Fuel type
- Diesel
- Rated horsepower
- 172 hp
- Rated PTO Power
- 163.09 hp (AGCO Allis specification)
- Drawbar Power @ Rated Engine Speed
- 136.49 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 7.6 L (466 ci)
- Bore / stroke
- 4.30x5.35 inches 109 x 136 mm
- Rated RPM
- 2200 RPM
- Crankcase oil capacity
- N/A
- Coolant capacity
- N/A
Maintenance picks for the 9455
Filters, oil and common wear parts for this model.
Transmission and chassis specifications
- Transmission type
- Four-speed power shift (32-speed)
- Gears (forward / reverse)
- 32 forward
- Drive system
- 4WD
- Wheelbase
- 116.5 in
- Front tire
- 11.00-16
- Rear tire
- 18.4R38
- Hydraulic flow
- N/A
- Rear hitch
- III/II
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for AGCO Allis 9455.
Theoretical draft formula suggests 19,780 lbs. Official manufacturer GVWR is unrecorded for this catalog entry, so target weight is constrained to an engineering structural estimate (~135% of base operating weight) to prevent chassis overload.
Engine demand (297.9 HP) exceeds rated power (172 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Tractor is currently light for this heavy draft tool. Add ~2191 kg (4,830 lbs) ballast to prevent tire slip and premature wear.
Target ballast is capped at 18,630 lbs based on structural engineering estimate (~135% base weight; official manufacturer GVWR unrecorded). Avoid adding excess ballast beyond this benchmark to protect axle bearings and chassis.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1994 | #955,001 | #955,500 | Factory not specified |
| 1995 | #955,501 | #956,300 | Factory not specified |
| 1996 | #956,301 | #956,413 | Factory not specified |
| 1997 | #956,414 | End of run | Factory not specified |
Instant Used Market Valuation Projector
Algorithmic resale estimate for AGCO Allis 9455 (1994)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used AGCO Allis 9455?
Browse live listings and auction results near you.
Compare similar machines
AGCO Allis
USA • 39 Models
AGCO Allis was a prominent name in the agricultural machinery industry, representing a significant chapter in the evolution of farm equipment manufacturing. The brand's origins trace back to the Deutz-Allis Corporation, a joint venture between Germany's Deutz-Fahr and the American Allis-Chalmers. In 1985, the North American division of Deutz-Allis was acquired by its U.S. management team, leading to the formation of AGCO (Allis-Gleaner Company) Allis. This strategic move aimed to revitalize the legacy of Allis-Chalmers, a storied American manufacturer known for its innovative agricultural machinery. Under the AGCO Allis brand, the company continued to produce a range of tractors and agricultural equipment, building on the engineering heritage of its predecessors. The brand's product line included robust and reliable tractors that were well-received by North American farmers. However, as part of AGCO's broader strategic restructuring, the AGCO Allis brand was phased out in 2001. This decision aligned with AGCO's global brand consolidation efforts, which focused on unifying its product offerings under its core brands such as Massey Ferguson, Fendt, and Valtra. Despite its relatively short lifespan, AGCO Allis played a crucial role in the transition of agricultural machinery manufacturing in North America, contributing to the industry's modernization and the development of advanced farming technologies.
