Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About 9670
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Deutz BF6L513R
- Fuel type
- Diesel
- Rated horsepower
- 194 hp
- Rated PTO Power
- 181.12 hp (AGCO Allis specification)
- Drawbar Power @ Rated Engine Speed
- 152.23 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 9.6 L (584 ci)
- Bore / stroke
- 4.92x5.12 inches 125 x 130 mm
- Rated RPM
- 2300 RPM
- Crankcase oil capacity
- 24 qts (~22.7 L)
- Coolant capacity
- N/A
Maintenance picks for the 9670
Oil capacity 24 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Full power shift (18F/9R)
- Gears (forward / reverse)
- 18 forward / 9 reverse
- Drive system
- 4WD
- Wheelbase
- 115 in
- Front tire
- 11.00-16
- Rear tire
- 20.8R38
- Hydraulic flow
- N/A
- Rear hitch
- III/II
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for AGCO Allis 9670.
Engine demand (343.8 HP) exceeds rated power (194 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Tractor is currently light for this heavy draft tool. Add ~1760 kg (3,880 lbs) ballast to prevent tire slip and premature wear.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1994 | #961,001 | #961,500 | Factory not specified |
| 1995 | #961,501 | End of run | Factory not specified |
