Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Detroit Diesel 12V92T
- Fuel type
- Diesel
- Rated horsepower
- 650 hp
- Rated PTO Power
- N/A (Big Bud specification)
- Cylinders
- 12
- Displacement
- 18.1 L (1104 ci)
- Bore / stroke
- 4.84x5.00 inches 123 x 127 mm
- Rated RPM
- 2100 RPM
- Crankcase oil capacity
- N/A
- Coolant capacity
- 128 qts (~121.1 L)
Maintenance picks for the 650/50
Filters, oil and common wear parts for this model.
Transmission and chassis specifications
- Transmission type
- Power shift (9F/2R)
- Gears (forward / reverse)
- 9 forward / 2 reverse
- Drive system
- 4WD
- Wheelbase
- 157 in
- Front tire
- 35.5-32
- Rear tire
- 35.5-32
- Hydraulic flow
- N/A
- Rear hitch
- N/A
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Big Bud 650/50.
Theoretical draft formula suggests 87,750 lbs. Official manufacturer GVWR is unrecorded for this catalog entry, so target weight is constrained to an engineering structural estimate (~135% of base operating weight) to prevent chassis overload.
Engine demand (706.4 HP) exceeds rated power (650 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Tractor is currently light for this heavy draft tool. Add ~8165 kg (18,000 lbs) ballast to prevent tire slip and premature wear.
Target ballast is capped at 78,000 lbs based on structural engineering estimate (~135% base weight; official manufacturer GVWR unrecorded). Avoid adding excess ballast beyond this benchmark to protect axle bearings and chassis.
Instant Used Market Valuation Projector
Algorithmic resale estimate for Big Bud 650/50 (1980)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used Big Bud 650/50?
Browse live listings and auction results near you.
Compare similar machines
Big Bud
USA • 30 Models
Big Bud Tractors Inc. emerged from the Wagner tractor dealership in Havre, Montana in 1961, establishing itself as a pioneering force in the heavy-duty tractor market. The company quickly gained recognition for its innovative approach, producing high-horsepower tractors designed for industrial applications. Big Bud's tractors were distinguished by their custom-built frames and the use of powerful industrial engines, setting new standards for performance and durability in the agricultural machinery industry. The company introduced several groundbreaking features, including tilt cabins and a skid system for engine removal, which further cemented its reputation for engineering excellence. Despite its innovative spirit and strong market presence, Big Bud faced challenges in the late 1980s, leading to its acquisition by Messner Brothers in 1985. Under new ownership, the company continued to operate but eventually ceased production in 1992, marking the end of an era for this iconic American tractor manufacturer.
