Case 900-B

Production years: 1957–1959 • Assembly plant: Racine, Wisconsin, USA

Compare with other modelsValue machine
Engine horsepower
78 HP
PTO: 70.24 HP
Displacement
6.2 L
6-cylinder engine
Drive and chassis
2WD
Gear (6F/1R)
Operating weight
3,855 kg
8,500 lbs

Sources and field evidence

Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.

Case 900-B
VLM Verified Authentic
Case 900-B

Ask TractorDex AI Copilot About 900-B

Instant technical consultation powered by heavy machinery knowledge

Engineering & Capability Benchmark

Specific output, tractive ratio, and segment percentile

Utility & Farmyard Workhorse
Global Tractor Fleet Power SpectrumTop 71% of all indexed machinery
Compact (20 HP)Utility (100 HP)Row-Crop (250 HP)Titans (600+ HP)
Specific Output
12.6 HP/L
Aspiration: Unknown
Traction Ratio
49.4 kg/HP
Heavy ballast for draft pull
PTO Efficiency
90%
70.24 PTO HP rated
Hydraulic Flow
Standard
Auxiliary implement ports

Engine and power specifications

Engine model
J.I. Case
Fuel type
Diesel
Rated horsepower
78 hp
Rated PTO Power
70.24 hp (Case specification)
Drawbar Power @ Rated Engine Speed
66.21 hp (Nebraska OECD Test 2218)
Cylinders
6
Displacement
6.2 L (377 ci)
Bore / stroke
4.00x5.00 inches 102 x 127 mm
Rated RPM
1500 RPM
Crankcase oil capacity
12 qts (~11.4 L)
Coolant capacity
N/A

Maintenance picks for the 900-B

Oil capacity 12 qts — match the filter before you drain.

Transmission and chassis specifications

Transmission type
Gear (6F/1R)
Gears (forward / reverse)
6 forward / 1 reverse
Drive system
2WD
Wheelbase
84 in
Front tire
7.50-18
Rear tire
15-34
Hydraulic flow
N/A
Rear hitch
N/A
ASABE EP496 Engineering Matcher

Implement Draft & Ballast Matcher

Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Case 900-B.

Overloaded / Wheel Slip Alert(119%)
CAD DRAFT SCHEMATIC • Wide-Span Field Cultivator
SOIL: Medium Tilled LoamDEPTH: 4"SPEED: 7 MPH119% LOAD
SOIL SURFACE (0.0")SUB-SURFACE PLOW PAN (~14")78 HP◄ 3,477 LBS DRAFT4" DEPTH
DRAWBAR DEMAND: 64.9 HPWIDTH / SIZE: 20 ft Width
ASABE D497.7 Tillage Specific Resistance Formula
Implement Size (ft Width)20 ft Width
18 ft WidthDefault: 4270 ft Width
Tillage / Seeding Depth4 inches (10 cm)
2"Target: 4"6"
Target Operating Field Speed7.0 mph (11.3 km/h)
5 mphRated: 7 mph9 mph
Engine Power Demand vs Rated Output92.7 HP / 78 HP Rated
0%55% (Min Load)60-85% (Sweet Spot)100% (Cap)
Draft Force
3,477 lbs
Drawbar Power
64.9 HP
Target Slip
8% - 12%
Axle Ballast Balance (2WD Standard Utility )Calibrated for Wide-Span Field Cultivator (100 lbs/HP standard)
Target: 7,800 lbs
Front Axle: 28%Rear Axle: 72%
991 kg (2,184 lbs)2,547 kg (5,616 lbs)
Ballast Adjustment vs Base:-700 lbs (-318 kg)
Hourly Diesel Burn
3.6 gal/h
13.6 L/hr (est. $14/h)
Hydraulic Fan Status
Standard Draw
No fan req

Engine demand (92.7 HP) exceeds rated power (78 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.

Catalog archival serial-number ranges

3 production years
Production yearStarting serial #Ending serial #Assembly plant
1957#8,100,001#8,120,000Racine, Wisconsin, USA
1958#8,120,001#8,140,000Racine, Wisconsin, USA
1959#8,140,001End of runRacine, Wisconsin, USA

Instant Used Market Valuation Projector

Algorithmic resale estimate for Case 900-B (1957)

Full Appraisal Tool
Operating Meter Hours3,200 hrs
Mechanical & Physical Condition
Empirical model calibrated against dealer & auction lots
Estimated Fair Market Value
$3,515
Basis: 78 HP • 69 yrs old
Auction / Wholesale
$2,882 – $3,234
Dealer Retail Asking
$3,691 – $4,148
3-Year Projected Resale Curve~5% annual retention decay
Year 2027
$3,339
Year 2028
$3,172
Year 2029
$3,014

Direct Segment Rivals & Showdowns

Head-to-head match-ups calibrated by horsepower and era

Chamberlain+12 HP
Super 90
90 HP
Deere+10 HP
4010
88 HP

Looking for a used Case 900-B?

Browse live listings and auction results near you.

Case

USA • 137 Models

Founded in 1842 by Jerome Increase Case, the J. I. Case Threshing Machine Company emerged as a pioneering force in agricultural machinery during the 19th century. The company gained early prominence by manufacturing steam engines, including portable engines and traction engines, which were crucial for mechanizing agriculture and construction in the United States. Alongside its steam engine innovations, Case became a leading producer of threshing machines and harvesting equipment, establishing itself as a cornerstone of American agricultural mechanization. By the early 20th century, Case expanded into the tractor market, becoming one of the largest tractor manufacturers globally. The company's commitment to quality and innovation earned it a reputation for robust and reliable machinery, serving both agricultural and construction sectors. In the mid-20th century, Case shifted its primary focus to construction equipment while maintaining a strong presence in agriculture. A pivotal moment in its history occurred in the 1980s when Case was acquired by Tenneco, leading to the 1985 merger with International Harvester's agricultural equipment division. This merger resulted in the formation of Case IH, a powerhouse brand that combined the legacies of two iconic agricultural machinery manufacturers. The new entity continued to innovate, introducing advanced technologies and expanding its global footprint.
