Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Caterpillar 3056C
- Fuel type
- Diesel
- Rated horsepower
- 168 hp
- Rated PTO Power
- 153.1 hp (Challenger specification)
- Drawbar Power @ Rated Engine Speed
- 125 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 6 L (365.2 ci)
- Bore / stroke
- 3.937x5.00 inches 100 x 127 mm
- Rated RPM
- 2200 RPM
- Crankcase oil capacity
- 20 qts (~18.9 L)
- Coolant capacity
- 26.92 qts (~25.5 L)
Maintenance picks for the MT565B
Oil capacity 20 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Continuously variable transmission (32-speed)
- Gears (forward / reverse)
- 32 forward
- Drive system
- 4WD
- Wheelbase
- 118.7 in
- Front tire
- 420/90R30
- Rear tire
- 520/85R42
- Hydraulic flow
- 29 GPM
- Rear hitch
- optional
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Challenger MT565B.
Engine demand (297.9 HP) exceeds rated power (168 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Tractor is currently light for this heavy draft tool. Add ~1524 kg (3,360 lbs) ballast to prevent tire slip and premature wear.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 2004 | #1 | End of run | Factory not specified |
| 2005 | #1 | End of run | Factory not specified |
| 2006 | #1 | End of run | Factory not specified |
| 2007 | #1 | End of run | Factory not specified |
