Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About E4
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Buda 6B230
- Fuel type
- Diesel
- Rated horsepower
- 47 hp
- Rated PTO Power
- 43 hp (CO-OP specification)
- Drawbar Power @ Rated Engine Speed
- 37.85 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 3.8 L (230 ci)
- Bore / stroke
- 3.4375x4.125 inches 87 x 105 mm
- Rated RPM
- 1650 RPM
- Crankcase oil capacity
- N/A
- Coolant capacity
- N/A
Maintenance picks for the E4
Filters, oil and common wear parts for this model.
Transmission and chassis specifications
- Transmission type
- Gear (6F/2R)
- Gears (forward / reverse)
- 6 forward / 2 reverse
- Drive system
- 2WD
- Wheelbase
- 86.7 in
- Front tire
- N/A
- Rear tire
- N/A
- Hydraulic flow
- N/A
- Rear hitch
- N/A
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for CO-OP E4.
Engine demand (83.4 HP) exceeds rated power (47 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1949 | #101 | #193 | Factory not specified |
| 1950 | #194 | #4,097 | Factory not specified |
| 1951 | #4,098 | #6,895 | Factory not specified |
| 1952 | #6,896 | #10,471 | Factory not specified |
| 1953 | #10,472 | #11,362 | Factory not specified |
| 1954 | #11,363 | #20,000 | Factory not specified |
| 1955 | #20,001 | #30,000 | Factory not specified |
| 1956 | #30,001 | #40,000 | Factory not specified |
| 1957 | #40,001 | #50,000 | Factory not specified |
| 1958 | #50,001 | End of run | Factory not specified |
Instant Used Market Valuation Projector
Algorithmic resale estimate for CO-OP E4 (1949)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used CO-OP E4?
Browse live listings and auction results near you.
Compare similar machines
CO-OP
USA • 15 Models
The CO-OP tractor brand emerged from a unique cooperative movement in the agricultural sector during the early 20th century. Founded in the 1930s, CO-OP tractors were conceived as a collaborative effort by farmers seeking affordable machinery through collective ownership and production. The brand's early models were designed by Dent Parrett, a former engineer from Parrett Tractor, and incorporated components from Chrysler, reflecting a pragmatic approach to manufacturing. Production initially took place in Michigan, but in 1938, the operation relocated to Indiana, signaling a period of growth and expansion. The brand's portfolio was further enriched by contributions from Cletrac, with some production also occurring in Saint Paul, Minnesota. A significant development came after World War II when CO-OP entered into an agreement with Cockshutt, leading to the introduction of the 'E' series tractors, which were essentially rebranded Cockshutt models. Despite these efforts, CO-OP faced challenges in the marketplace, and by 1952, the brand's facilities were sold to Cockshutt due to poor sales performance. This marked the end of the CO-OP tractor brand, which was subsequently discontinued.
