Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About 1850
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Waukesha-Oliver
- Fuel type
- Gasoline
- Rated horsepower
- 102 hp
- Rated PTO Power
- 92.94 hp (Cockshutt specification)
- Drawbar Power @ Rated Engine Speed
- 84.52 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 5.1 L (310 ci)
- Bore / stroke
- 3.875x4.375 inches 98 x 111 mm
- Rated RPM
- 2400 RPM
- Crankcase oil capacity
- 8 qts (~7.6 L)
- Coolant capacity
- 20 qts (~18.9 L)
Maintenance picks for the 1850
Oil capacity 8 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Unsynchronized (18F/6R)
- Gears (forward / reverse)
- 18 forward / 6 reverse
- Drive system
- 4WD
- Wheelbase
- 86.25 in
- Front tire
- 7.50-15
- Rear tire
- 18.4-34
- Hydraulic flow
- N/A
- Rear hitch
- II
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Cockshutt 1850.
Optimal engine load (98%). Tractive efficiency is peaked within standard 8% - 12% slip window.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1964 | #150,421 | #153,013 | Factory not specified |
| 1965 | #153,014 | #168,126 | Factory not specified |
| 1966 | #168,127 | #183,381 | Factory not specified |
| 1967 | #183,382 | #200,359 | Factory not specified |
| 1968 | #200,360 | #212,672 | Factory not specified |
| 1969 | #212,673 | End of run | Factory not specified |
