Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- John Deere
- Fuel type
- Diesel
- Rated horsepower
- 250 hp
- Rated PTO Power
- 252.21 hp (Deere specification)
- Drawbar Power @ Rated Engine Speed
- 202.28 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 8.1 L (496 ci)
- Bore / stroke
- 4.56x5.06 inches 116 x 129 mm
- Rated RPM
- 2200 RPM
- Crankcase oil capacity
- 29.6 qts (~28.0 L)
- Coolant capacity
- 30 qts (~28.4 L)
Maintenance picks for the 8400
Oil capacity 29.6 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Full power shift (16F/4R)
- Gears (forward / reverse)
- 16 forward / 4 reverse
- Drive system
- 4WD
- Wheelbase
- 116.1 in
- Front tire
- 14.9R34
- Rear tire
- 18.4R46
- Hydraulic flow
- N/A
- Rear hitch
- III/IIIN
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Deere 8400.
Engine demand (343.8 HP) exceeds rated power (250 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Tractor is currently light for this heavy draft tool. Add ~2268 kg (5,000 lbs) ballast to prevent tire slip and premature wear.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1995 | #1,001 | #6,000 | Waterloo, Iowa, USA |
| 1996 | #6,001 | #10,000 | Waterloo, Iowa, USA |
| 1997 | #10,001 | #20,000 | Waterloo, Iowa, USA |
| 1998 | #20,001 | #24,000 | Waterloo, Iowa, USA |
| 1999 | #24,001 | End of run | Waterloo, Iowa, USA |
