Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About 1466
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- International Harvester DT-436
- Fuel type
- Diesel
- Rated horsepower
- 147 hp
- Rated PTO Power
- 145.77 hp (Farmall specification)
- Drawbar Power @ Rated Engine Speed
- 123.2 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 7.1 L (436 ci)
- Bore / stroke
- 4.30x5.00 inches 109 x 127 mm
- Rated RPM
- 2400 RPM
- Crankcase oil capacity
- 18 qts (~17.0 L)
- Coolant capacity
- 27 qts (~25.5 L)
Maintenance picks for the 1466
Oil capacity 18 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Gear (16F/8R)
- Gears (forward / reverse)
- 16 forward / 8 reverse
- Drive system
- 4WD
- Wheelbase
- 105 in
- Front tire
- 11L-15
- Rear tire
- 18.4-38
- Hydraulic flow
- 21 GPM
- Rear hitch
- II/II Opt Optional
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Farmall 1466.
Engine demand (149.7 HP) exceeds rated power (147 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1971 | #7,101 | #10,407 | Factory not specified |
| 1972 | #10,408 | #15,532 | Factory not specified |
| 1973 | #15,533 | #19,745 | Factory not specified |
| 1974 | #19,746 | #25,403 | Factory not specified |
| 1975 | #25,404 | #29,515 | Factory not specified |
| 1976 | #29,516 | End of run | Factory not specified |
Instant Used Market Valuation Projector
Algorithmic resale estimate for Farmall 1466 (1971)
