Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- International Harvester
- Fuel type
- Gasoline
- Rated horsepower
- 38 hp
- Rated PTO Power
- 36.07 hp (Farmall specification)
- Drawbar Power @ Rated Engine Speed
- 33.1 hp (Nebraska OECD Test 2218)
- Cylinders
- 4
- Displacement
- 4.1 L (247.7 ci)
- Bore / stroke
- 3.875x5.25 inches 98 x 133 mm
- Rated RPM
- 1450 RPM
- Crankcase oil capacity
- 8 qts (~7.6 L)
- Coolant capacity
- 24 qts (~22.7 L)
Maintenance picks for the M
Oil capacity 8 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Sliding gear (5F/1R)
- Gears (forward / reverse)
- 5 forward / 1 reverse
- Drive system
- 2WD
- Wheelbase
- 88.5 in
- Front tire
- 6.00-16
- Rear tire
- 11-38
- Hydraulic flow
- N/A
- Rear hitch
- N/A
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Farmall M.
Engine demand (83.4 HP) exceeds rated power (38 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1939 | #501 | #7,239 | Factory not specified |
| 1940 | #7,240 | #25,370 | Factory not specified |
| 1941 | #25,371 | #50,987 | Factory not specified |
| 1942 | #50,988 | #60,010 | Factory not specified |
| 1943 | #60,011 | #67,423 | Factory not specified |
| 1944 | #67,424 | #88,084 | Factory not specified |
| 1945 | #88,085 | #105,563 | Factory not specified |
| 1946 | #105,564 | #122,822 | Factory not specified |
| 1947 | #122,823 | #151,707 | Factory not specified |
| 1948 | #151,708 | #180,513 | Factory not specified |
| 1949 | #180,514 | #213,578 | Factory not specified |
| 1950 | #213,579 | #247,517 | Factory not specified |
| 1951 | #247,518 | #290,922 | Factory not specified |
| 1952 | #290,923 | End of run | Factory not specified |
