Engine and power specifications
- Engine model
- Fiat 8065.05
- Fuel type
- Diesel
- Rated horsepower
- 110 hp
- Rated PTO Power
- N/A (Fiat specification)
- Cylinders
- 6
- Displacement
- 5.9 L (357.6 ci)
- Bore / stroke
- 4.0945x4.53 inches 104 x 115 mm
- Rated RPM
- 2500 RPM
- Crankcase oil capacity
- 14.4 qts (~13.6 L)
- Coolant capacity
- N/A
Maintenance picks for the 110-90
Oil capacity 14.4 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Synchronized (20F/4R)
- Gears (forward / reverse)
- 20 forward / 4 reverse
- Drive system
- Unknown
- Wheelbase
- 101.57 in
- Front tire
- 7.50-20
- Rear tire
- 16.9/14-38
- Hydraulic flow
- N/A
- Rear hitch
- N/A
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Fiat 110-90.
Ballast distribution and traction efficiency depend directly on chassis drive type. Please select your tractor's configuration:
Engine demand (129.9 HP) exceeds rated power (110 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Instant Used Market Valuation Projector
Algorithmic resale estimate for Fiat 110-90 (1986)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used Fiat 110-90?
Browse live listings and auction results near you.
Compare similar machines
Fiat
Italy • 165 Models
Fiat Trattori S.p.A., founded in 1919, emerged as a pioneering force in the agricultural machinery sector, particularly in the realm of tractors. As Italy's leading tractor manufacturer and one of Europe's largest, Fiat Trattori quickly established itself as a cornerstone of the European agricultural landscape. The company's early innovations and robust engineering set a benchmark for tractor design and functionality, making it a trusted name among farmers across the continent. A pivotal moment in Fiat Trattori's history came in 1991 when it strategically acquired Ford-New Holland, a move that significantly broadened its global footprint and product offerings. This acquisition was followed by another landmark event in 1999 when New Holland, under Fiat's ownership, merged with Case Corporation to form CNH Global. Fiat Industrial, as the majority shareholder, played a crucial role in steering this new entity, which became a dominant player in the agricultural machinery market. The consolidation continued in 2013 when Fiat Industrial and CNH Global merged to create CNH Industrial, effectively integrating Fiat Trattori into a larger, more diversified global conglomerate. This merger marked the end of Fiat Trattori as an independent brand but underscored its lasting impact on the industry through its technological contributions and legacy models.
