Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About 3230
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Ford
- Fuel type
- Diesel
- Rated horsepower
- 37 hp
- Rated PTO Power
- 32.33 hp (Ford specification)
- Drawbar Power @ Rated Engine Speed
- 26.03 hp (Nebraska OECD Test 2218)
- Cylinders
- 3
- Displacement
- 3.1 L (192 ci)
- Bore / stroke
- 4.40x4.20 inches 112 x 107 mm
- Rated RPM
- 2000 RPM
- Crankcase oil capacity
- N/A
- Coolant capacity
- 11 qts (~10.4 L)
Maintenance picks for the 3230
Filters, oil and common wear parts for this model.
Transmission and chassis specifications
- Transmission type
- N/A
- Gears (forward / reverse)
- 8 forward / 2 reverse
- Drive system
- 4WD
- Wheelbase
- 84.1 in
- Front tire
- 6.00-16
- Rear tire
- 12.4-28
- Hydraulic flow
- N/A
- Rear hitch
- 2/1
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Ford 3230.
Engine demand (74.9 HP) exceeds rated power (37 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1990 | #26,239 | #68,790 | Factory not specified |
| 1991 | #68,791 | End of run | Factory not specified |
| 1992 | #7,628 | #32,444 | Factory not specified |
| 1993 | #32,445 | #68,790 | Factory not specified |
| 1994 | #68,791 | End of run | Factory not specified |
Instant Used Market Valuation Projector
Algorithmic resale estimate for Ford 3230 (1990)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used Ford 3230?
Browse live listings and auction results near you.
Compare similar machines
Ford
USA • 165 Models
Ford, a division of the Ford Motor Company, is a pioneering force in the agricultural machinery sector with a legacy spanning over a century. Founded in 1900, Ford initially gained prominence with the Fordson Model F, which became one of the most successful tractors globally, selling over 650,000 units. However, it was the introduction innovative N-series tractors that truly cemented Ford's reputation in agriculture. Introduced in 1939, the 9N was the first American-made production tractor to feature Harry Ferguson's three-point hitch system, a revolutionary design that transformed tractor versatility and efficiency. This innovation set a new industry standard, significantly improving the tractor's ability to perform a wide range of agricultural tasks. The subsequent models, the 2N and 8N, built upon this legacy. The 2N, released in 1942, was adapted to wartime manufacturing constraints, while the 8N, launched in 1947, offered increased power and an enhanced transmission, becoming one of the most popular farm tractors in North America with over 530,000 units sold worldwide.
