International Harvester 1466

Production years: 1971–1976 • Assembly plant: Rock Island, Illinois (Farmall Works), USA

Compare with other modelsValue machine
Engine horsepower
147 HP
PTO: 145.77 HP
Displacement
7.1 L
6-cylinder engine
Drive and chassis
4WD
Gear (16F/8R)
Operating weight
6,114 kg
13,480 lbs

Sources and field evidence

Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.

International Harvester 1466 - Farmall 1466 tractor MD1
VLM Verified Authentic
1/4
International Harvester 1466 - Farmall 1466 tractor MD1
Photo: © Acroterion via Wikimedia CommonsCC BY-SA 4.0Source
Verified Perspective Gallery (4 views)1 / 4

Ask TractorDex AI Copilot About 1466

Instant technical consultation powered by heavy machinery knowledge

Engineering & Capability Benchmark

Specific output, tractive ratio, and segment percentile

Row-Crop / Mid-Range Field
Global Tractor Fleet Power SpectrumTop 51% of all indexed machinery
Compact (20 HP)Utility (100 HP)Row-Crop (250 HP)Titans (600+ HP)
Specific Output
20.7 HP/L
Turbocharged
Traction Ratio
41.6 kg/HP
Agile transport & crop care
PTO Efficiency
99%
145.77 PTO HP rated
Hydraulic Flow
21 GPM
79 L/min capacity

Engine and power specifications

Engine model
International Harvester DT-436
Fuel type
Diesel
Rated horsepower
147 hp
Rated PTO Power
145.77 hp (International Harvester specification)
Drawbar Power @ Rated Engine Speed
123.2 hp (Nebraska OECD Test 2218)
Cylinders
6
Displacement
7.1 L (436 ci)
Bore / stroke
4.30x5.00 inches 109 x 127 mm
Rated RPM
2400 RPM
Crankcase oil capacity
18 qts (~17.0 L)
Coolant capacity
27 qts (~25.5 L)

Maintenance picks for the 1466

Oil capacity 18 qts — match the filter before you drain.

Transmission and chassis specifications

Transmission type
Gear (16F/8R)
Gears (forward / reverse)
16 forward / 8 reverse
Drive system
4WD
Wheelbase
105 in
Front tire
11L-15
Rear tire
18.4-38
Hydraulic flow
21 GPM
Rear hitch
II/II Opt Optional
ASABE EP496 Engineering Matcher

Implement Draft & Ballast Matcher

Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for International Harvester 1466.

Overloaded / Wheel Slip Alert(102%)
CAD DRAFT SCHEMATIC • Wide-Span Field Cultivator
SOIL: Medium Tilled LoamDEPTH: 4"SPEED: 7 MPH102% LOAD
SOIL SURFACE (0.0")SUB-SURFACE PLOW PAN (~14")147 HP◄ 6,258 LBS DRAFT4" DEPTH
DRAWBAR DEMAND: 116.8 HPWIDTH / SIZE: 36 ft Width
ASABE D497.7 Tillage Specific Resistance Formula
Implement Size (ft Width)36 ft Width
18 ft WidthDefault: 4270 ft Width
Tillage / Seeding Depth4 inches (10 cm)
2"Target: 4"6"
Target Operating Field Speed7.0 mph (11.3 km/h)
5 mphRated: 7 mph9 mph
Engine Power Demand vs Rated Output149.7 HP / 147 HP Rated
0%55% (Min Load)60-85% (Sweet Spot)100% (Cap)
Draft Force
6,258 lbs
Drawbar Power
116.8 HP
Target Slip
8% - 12%
Axle Ballast Balance (MFWD / Mechanical Front Assist )Calibrated for Wide-Span Field Cultivator (100 lbs/HP standard)
Target: 14,700 lbs
Front Axle: 38%Rear Axle: 62%
2,534 kg (5,586 lbs)4,134 kg (9,114 lbs)
Ballast Adjustment vs Base:+1,220 lbs (553 kg)
Hourly Diesel Burn
6.6 gal/h
25 L/hr (est. $25/h)
Hydraulic Fan Status
Standard Draw
No fan req

Engine demand (149.7 HP) exceeds rated power (147 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.

Catalog archival serial-number ranges

6 production years
Production yearStarting serial #Ending serial #Assembly plant
1971#7,101#10,407Rock Island, Illinois (Farmall Works), USA
1972#10,408#15,532Rock Island, Illinois (Farmall Works), USA
1973#15,533#19,745Rock Island, Illinois (Farmall Works), USA
1974#19,746#25,403Rock Island, Illinois (Farmall Works), USA
1975#25,404#29,515Rock Island, Illinois (Farmall Works), USA
1976#29,516End of runRock Island, Illinois (Farmall Works), USA

Instant Used Market Valuation Projector

Algorithmic resale estimate for International Harvester 1466 (1971)

Full Appraisal Tool
Operating Meter Hours3,200 hrs
Mechanical & Physical Condition
Empirical model calibrated against dealer & auction lots
Estimated Fair Market Value
$6,606
Basis: 147 HP • 55 yrs old
Auction / Wholesale
$5,417 – $6,078
Dealer Retail Asking
$6,936 – $7,795
3-Year Projected Resale Curve~5% annual retention decay
Year 2027
$6,276
Year 2028
$5,962
Year 2029
$5,664

Direct Segment Rivals & Showdowns

Head-to-head match-ups calibrated by horsepower and era

Minneapolis-Moline+22 HP
A4T-1600
169 HP
Oliver+22 HP
2655
169 HP
White+21 HP
4-150
168 HP
