Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About 254
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Mitsubishi
- Fuel type
- Diesel
- Rated horsepower
- 24 hp
- Rated PTO Power
- 21 hp (International Harvester specification)
- Cylinders
- 3
- Displacement
- 1.1 L (64.75 ci)
- Bore / stroke
- 2.99x3.07 inches 76 x 78 mm
- Rated RPM
- 2800 RPM
- Crankcase oil capacity
- 4.4 qts (~4.2 L)
- Coolant capacity
- 5.2 qts (~4.9 L)
Maintenance picks for the 254
Oil capacity 4.4 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Gear (9F/3R)
- Gears (forward / reverse)
- 9 forward / 3 reverse
- Drive system
- 4WD
- Wheelbase
- 60 in
- Front tire
- 5.00-15
- Rear tire
- 11.2-24
- Hydraulic flow
- N/A
- Rear hitch
- 1
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for International Harvester 254.
Theoretical draft formula suggests 2,400 lbs. Official manufacturer GVWR is unrecorded for this catalog entry, so target weight is constrained to an engineering structural estimate (~135% of base operating weight) to prevent chassis overload.
Engine demand (74.9 HP) exceeds rated power (24 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Target ballast is capped at 2,376 lbs based on structural engineering estimate (~135% base weight; official manufacturer GVWR unrecorded). Avoid adding excess ballast beyond this benchmark to protect axle bearings and chassis.
