Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About 1155
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Perkins AV8.540
- Fuel type
- Diesel
- Rated horsepower
- 155 hp
- Rated PTO Power
- 140.97 hp (Massey Ferguson specification)
- Drawbar Power @ Rated Engine Speed
- 117.8 hp (Nebraska OECD Test 2218)
- Cylinders
- 8
- Displacement
- 8.9 L (540 ci)
- Bore / stroke
- 4.25x4.75 inches 108 x 121 mm
- Rated RPM
- 2200 RPM
- Crankcase oil capacity
- 20 qts (~18.9 L)
- Coolant capacity
- 50 qts (~47.3 L)
Maintenance picks for the 1155
Oil capacity 20 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Two-speed power shift (8F/2R)
- Gears (forward / reverse)
- 8 forward / 2 reverse
- Drive system
- 2WD
- Wheelbase
- 109 in
- Front tire
- 14L-16
- Rear tire
- 18.4-38
- Hydraulic flow
- N/A
- Rear hitch
- II/III
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Massey Ferguson 1155.
Engine demand (166.9 HP) exceeds rated power (155 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1972 | #936,563 | #936,850 | Factory not specified |
| 1973 | #936,851 | #942,684 | Factory not specified |
| 1974 | #942,685 | #950,493 | Factory not specified |
| 1975 | #950,494 | #958,734 | Factory not specified |
| 1976 | #958,735 | #966,275 | Factory not specified |
| 1977 | #966,276 | #974,240 | Factory not specified |
| 1978 | #974,241 | #976,057 | Factory not specified |
| 1979 | #976,058 | End of run | Factory not specified |
Instant Used Market Valuation Projector
Algorithmic resale estimate for Massey Ferguson 1155 (1973)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used Massey Ferguson 1155?
Browse live listings and auction results near you.
Compare similar machines
Massey Ferguson
Canada • 684 Models
Massey Ferguson is a prominent manufacturer of agricultural machinery with a rich history in the industry. The company was established in 1953 as a result of a merger between two significant farm equipment manufacturers: Massey-Harris of Canada and the Ferguson Company of Northern Ireland. This union brought together the expertise and legacy of both entities, positioning Massey Ferguson as a major player in the global agricultural machinery market. Initially based in Coventry, England, the company underwent a significant relocation in 2003 when its Coventry factory was closed, and operations were moved to Beauvais, France. This move marked a new chapter in the company's history, reflecting its ongoing adaptation to the evolving demands of the agricultural sector. Massey Ferguson's commitment to innovation and quality has been a hallmark of its brand, making it a trusted name among farmers and agricultural professionals worldwide.
