Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About TD-40
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- International Harvester
- Fuel type
- Diesel
- Rated horsepower
- 53 hp
- Rated PTO Power
- N/A (McCormick-Deering specification)
- Drawbar Power @ Rated Engine Speed
- 48.53 hp (Nebraska OECD Test 2218)
- Cylinders
- 4
- Displacement
- 7.6 L (460.7 ci)
- Bore / stroke
- 4.75x6.50 inches 121 x 165 mm
- Rated RPM
- 1100 RPM
- Crankcase oil capacity
- 12 qts (~11.4 L)
- Coolant capacity
- 60 qts (~56.8 L)
Maintenance picks for the TD-40
Oil capacity 12 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- N/A
- Gears (forward / reverse)
- 5 forward / 1 reverse
- Drive system
- Tracks (Crawler)
- Wheelbase
- N/A
- Front tire
- N/A
- Rear tire
- N/A
- Hydraulic flow
- N/A
- Rear hitch
- N/A
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for McCormick-Deering TD-40.
Engine demand (70.4 HP) exceeds rated power (53 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Tractor exceeds target ballast by 3221 kg. Consider removing wheel weights to reduce soil compaction.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1933 | #973 | #1,471 | Factory not specified |
| 1934 | #1,472 | #3,068 | Factory not specified |
| 1935 | #3,069 | #4,650 | Factory not specified |
| 1936 | #4,651 | #6,653 | Factory not specified |
| 1937 | #6,654 | #7,921 | Factory not specified |
| 1938 | #7,922 | End of run | Factory not specified |
Instant Used Market Valuation Projector
Algorithmic resale estimate for McCormick-Deering TD-40 (1933)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used McCormick-Deering TD-40?
Browse live listings and auction results near you.
Compare similar machines
McCormick-Deering
USA • 42 Models
McCormick-Deering was a prominent brand in agricultural machinery during the early 20th century, closely associated with International Harvester. The brand's origins trace back to Cyrus McCormick, who revolutionized farming with the invention of the first successful mechanical reaper in 1831. This innovation laid the groundwork for what would eventually become International Harvester, a conglomerate formed from the merger of McCormick Harvesting Machine Company and other entities. In 1923, International Harvester introduced the McCormick-Deering brand to market its new line of standard (wide) front tractors, including the popular 10-20 and 15-30 models. These tractors were designed to meet the demands of American and international farmers, providing reliable and powerful machinery for a variety of agricultural tasks. The McCormick-Deering name adorned tractors and machinery for the next three decades, becoming synonymous with durability and innovation in the agricultural sector. However, by the mid-20th century, the brand was phased out as International Harvester consolidated its product lines under the International name. Today, McCormick-Deering is remembered as a significant chapter in the history of agricultural machinery, representing a period of rapid technological advancement and the transition to mechanized farming.
