Sources and field evidence
Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.
Ask TractorDex AI Copilot About MTX175
Instant technical consultation powered by heavy machinery knowledge
Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Perkins 1006-60TWI
- Fuel type
- Diesel
- Rated horsepower
- 176 hp
- Rated PTO Power
- N/A (McCormick Intl specification)
- Cylinders
- 6
- Displacement
- 6 L (365 ci)
- Bore / stroke
- 3.937x5.00 inches 100 x 127 mm
- Rated RPM
- 2200 RPM
- Crankcase oil capacity
- N/A
- Coolant capacity
- N/A
Maintenance picks for the MTX175
Filters, oil and common wear parts for this model.
Transmission and chassis specifications
- Transmission type
- Four-speed power shift (32F/24R)
- Gears (forward / reverse)
- 32 forward / 24 reverse
- Drive system
- 4WD
- Wheelbase
- 112.2 in
- Front tire
- 540/65R30
- Rear tire
- 650/65R42
- Hydraulic flow
- N/A
- Rear hitch
- III
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for McCormick Intl MTX175.
Engine demand (320.9 HP) exceeds rated power (176 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Tractor is currently light for this heavy draft tool. Add ~1597 kg (3,520 lbs) ballast to prevent tire slip and premature wear.
Instant Used Market Valuation Projector
Algorithmic resale estimate for McCormick Intl MTX175 (2000)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used McCormick Intl MTX175?
Browse live listings and auction results near you.
Compare similar machines
McCormick Intl
United Kingdom • 177 Models
McCormick International is a tractor brand with a rich heritage rooted in agricultural machinery manufacturing. The brand was revived in 2000 by ARGO, an Italian agricultural machinery conglomerate, which acquired the rights to the historic McCormick name and began producing tractors at the former International Harvester factory in Doncaster, England. This strategic move allowed ARGO to leverage the esteemed McCormick brand, which dates back to the 19th century when Cyrus Hall McCormick pioneered mechanical reapers, revolutionizing farming practices. The modern McCormick tractors are designed to carry forward this legacy of innovation and reliability in the agricultural sector. ARGO's acquisition of the McCormick name was part of a broader industry realignment following the merger of Case and International Harvester, which led to regulatory requirements for divestiture of certain assets. Under ARGO's stewardship, McCormick has continued to develop a range of tractors that cater to diverse farming needs, from small-scale operations to large commercial farms. The brand's product line reflects a commitment to modern technology while honoring its historical roots.
