Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- New Holland
- Fuel type
- Diesel
- Rated horsepower
- 140 hp
- Rated PTO Power
- 111.8 hp (New Holland specification)
- Drawbar Power @ Rated Engine Speed
- 81.3 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 7.5 L (456 ci)
- Bore / stroke
- 4.40x5.00 inches 112 x 127 mm
- Rated RPM
- 2200 RPM
- Crankcase oil capacity
- 18 qts (~17.0 L)
- Coolant capacity
- 26 qts (~24.6 L)
Maintenance picks for the TV140
Oil capacity 18 qts — match the filter before you drain.
Transmission and chassis specifications
- Transmission type
- Hydrostatic
- Gears (forward / reverse)
- N/A
- Drive system
- 4WD
- Wheelbase
- 118.1 in
- Front tire
- 16.9-28
- Rear tire
- 16.9-28
- Hydraulic flow
- N/A
- Rear hitch
- II
