Engineering & Capability Benchmark
Specific output, tractive ratio, and segment percentile
Engine and power specifications
- Engine model
- Waukesha-Oliver
- Fuel type
- Gasoline
- Rated horsepower
- 52 hp
- Rated PTO Power
- 47 hp (Cockshutt specification)
- Drawbar Power @ Rated Engine Speed
- 44.38 hp (Nebraska OECD Test 2218)
- Cylinders
- 6
- Displacement
- 3.5 L (216.5 ci)
- Bore / stroke
- 3.50x3.75 inches 89 x 95 mm
- Rated RPM
- 1750 RPM
- Crankcase oil capacity
- N/A
- Coolant capacity
- 18 qts (~17.0 L)
Maintenance picks for the 770
Filters, oil and common wear parts for this model.
Transmission and chassis specifications
- Transmission type
- Sliding gear (12F/4R)
- Gears (forward / reverse)
- 12 forward / 4 reverse
- Drive system
- 2WD
- Wheelbase
- N/A
- Front tire
- 6.00-16
- Rear tire
- 15.5-38
- Hydraulic flow
- N/A
- Rear hitch
- I/II
Implement Draft & Ballast Matcher
Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Cockshutt 770.
Engine demand (83.4 HP) exceeds rated power (52 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.
Catalog archival serial-number ranges
| Production year | Starting serial # | Ending serial # | Assembly plant |
|---|---|---|---|
| 1958 | #60,504 | #71,000 | Factory not specified |
| 1959 | #71,001 | #84,553 | Factory not specified |
| 1960 | #84,554 | #111,471 | Factory not specified |
| 1961 | #111,472 | #117,599 | Factory not specified |
| 1962 | #117,600 | #127,318 | Factory not specified |
| 1963 | #127,319 | #141,900 | Factory not specified |
| 1964 | #141,901 | #153,254 | Factory not specified |
| 1965 | #153,255 | #171,514 | Factory not specified |
| 1966 | #171,515 | #183,648 | Factory not specified |
| 1967 | #183,649 | End of run | Factory not specified |
Instant Used Market Valuation Projector
Algorithmic resale estimate for Cockshutt 770 (1963)
Direct Segment Rivals & Showdowns
Head-to-head match-ups calibrated by horsepower and era
Looking for a used Cockshutt 770?
Browse live listings and auction results near you.
Compare similar machines
Cockshutt
Canada • 41 Models
Cockshutt is a historically significant Canadian agricultural machinery brand with roots tracing back to the late 19th century. The company's origins lie in the Cockshutt family's various businesses, which eventually led to the establishment of the Cockshutt Plow Company in 1910. This marked the beginning of the company's formal entry into the agricultural equipment market. However, it was in 1946 that Cockshutt made its most notable contribution to the industry by becoming the first Canadian manufacturer to produce a line of modern farm tractors. This breakthrough established Cockshutt as a pioneering force in the Canadian agricultural machinery sector. The company's tractors were known for their innovative design and reliability, which quickly gained them a strong reputation among farmers. In 1961, Cockshutt's tractor manufacturing operations were acquired by the White Motor Company, which later became White Tractor. This acquisition marked a significant turning point in the brand's history, as it integrated Cockshutt's expertise into a larger organization while continuing to leverage its established brand name and product legacy.
