Minneapolis 27-42

Production years: 1928–1929

Compare with other modelsValue machine
Engine horsepower
46 HP
—
Displacement
8.6 L
4-cylinder engine
Drive and chassis
2WD
Gear (2F/1R)
Operating weight
3,084 kg
6,800 lbs

Sources and field evidence

Catalog Archive: Baseline specifications compiled from historical manufacturer archives and equipment registries. Laboratory test report verification in progress.

Minneapolis 27-42
VLM Verified Authentic
Minneapolis 27-42

Ask TractorDex AI Copilot About 27-42

Instant technical consultation powered by heavy machinery knowledge

Engineering & Capability Benchmark

Specific output, tractive ratio, and segment percentile

Compact / Sub-Compact Yard
Global Tractor Fleet Power SpectrumTop 82% of all indexed machinery
Compact (20 HP)Utility (100 HP)Row-Crop (250 HP)Titans (600+ HP)
Specific Output
5.3 HP/L
Aspiration: Unknown
Traction Ratio
67.0 kg/HP
Heavy ballast for draft pull
PTO Efficiency
—
Mechanical driveline
Hydraulic Flow
Standard
Auxiliary implement ports

Engine and power specifications

Engine model
Minneapolis Threshing Machine
Fuel type
Gasoline
Rated horsepower
46 hp
Rated PTO Power
N/A (Minneapolis specification)
Drawbar Power @ Rated Engine Speed
34.3 hp (Nebraska OECD Test 2218)
Cylinders
4
Displacement
8.6 L (522.6 ci)
Bore / stroke
4.875x7.00 inches 124 x 178 mm
Rated RPM
925 RPM
Crankcase oil capacity
N/A
Coolant capacity
34 qts (~32.2 L)

Maintenance picks for the 27-42

Filters, oil and common wear parts for this model.

Transmission and chassis specifications

Transmission type
Gear (2F/1R)
Gears (forward / reverse)
2 forward / 1 reverse
Drive system
2WD
Wheelbase
90.75 in
Front tire
36x5
Rear tire
53x12
Hydraulic flow
N/A
Rear hitch
N/A
ASABE EP496 Engineering Matcher

Implement Draft & Ballast Matcher

Simulate draft resistance, drawbar power transfer, and optimal axle weight distribution for Minneapolis 27-42.

Overloaded / Wheel Slip Alert(181%)
CAD DRAFT SCHEMATIC • Wide-Span Field Cultivator
SOIL: Medium Tilled LoamDEPTH: 4"SPEED: 7 MPH181% LOAD
SOIL SURFACE (0.0")SUB-SURFACE PLOW PAN (~14")46 HP◄ 3,129 LBS DRAFT4" DEPTH
DRAWBAR DEMAND: 58.4 HPWIDTH / SIZE: 18 ft Width
ASABE D497.7 Tillage Specific Resistance Formula
Implement Size (ft Width)18 ft Width
18 ft WidthDefault: 4270 ft Width
Tillage / Seeding Depth4 inches (10 cm)
2"Target: 4"6"
Target Operating Field Speed7.0 mph (11.3 km/h)
5 mphRated: 7 mph9 mph
Engine Power Demand vs Rated Output83.4 HP / 46 HP Rated
0%55% (Min Load)60-85% (Sweet Spot)100% (Cap)
Draft Force
3,129 lbs
Drawbar Power
58.4 HP
Target Slip
8% - 12%
Axle Ballast Balance (2WD Standard Utility )Calibrated for Wide-Span Field Cultivator (100 lbs/HP standard)
Target: 4,600 lbs
Front Axle: 28%Rear Axle: 72%
584 kg (1,288 lbs)1,502 kg (3,312 lbs)
Ballast Adjustment vs Base:-2,200 lbs (-998 kg)
Hourly Gasoline Burn
3.1 gal/h
11.7 L/hr (est. $11/h)
Hydraulic Fan Status
Standard Draw
No fan req

Engine demand (83.4 HP) exceeds rated power (46 HP). Reduce working speed by 1.0-1.5 mph or reduce working width.

Instant Used Market Valuation Projector

Algorithmic resale estimate for Minneapolis 27-42 (1928)

Full Appraisal Tool
Operating Meter Hours3,200 hrs
Mechanical & Physical Condition
Empirical model calibrated against dealer & auction lots
Estimated Fair Market Value
$2,079
Basis: 46 HP • 98 yrs old
Auction / Wholesale
$1,705 – $1,913
Dealer Retail Asking
$2,183 – $2,453
3-Year Projected Resale Curve~5% annual retention decay
Year 2027
$1,975
Year 2028
$1,876
Year 2029
$1,782

Direct Segment Rivals & Showdowns

Head-to-head match-ups calibrated by horsepower and era

McCormick-Deering+7 HP
TD-40
53 HP
Advance-Rumely+4 HP
OilPull R 25/45
50 HP
Aultman & Taylor+4 HP
22-45
50 HP

Looking for a used Minneapolis 27-42?

Browse live listings and auction results near you.

Minneapolis

USA • 11 Models

The Minneapolis Threshing Machine Company, established in 1887, was a pioneering force in the agricultural machinery industry, particularly known for its steam engines and threshing machines. Initially, the company distributed products from Huber and Allis before developing its own designs. A significant milestone in its history came in 1910 when Minneapolis entered the gasoline tractor market, producing a range of tractors that reached up to 80 horsepower. This move solidified its reputation as a key player in the early mechanization of American agriculture. However, the Great Depression posed significant challenges, leading to a strategic merger in 1929. Minneapolis Threshing Machine joined forces with Minneapolis Steel & Machinery and Moline Plow to form Minneapolis-Moline, a new entity that aimed to combine resources and weather the economic storm. This merger marked the beginning of a new chapter, as Minneapolis-Moline continued to innovate in the tractor and agricultural machinery space. While the Minneapolis brand itself eventually became part of the Minneapolis-Moline legacy, its contributions to the development of early gasoline tractors and its role in the consolidation of agricultural machinery manufacturers remain significant. The story of Minneapolis is emblematic of the evolution of the American agricultural industry, reflecting the trends of consolidation and technological advancement that defined the early 20th century.
